The Fluke 179 True RMS Digital Multimeter is a versatile, industry-standard tool for troubleshooting electrical and electronic systems․ It offers high accuracy, durability, and advanced features․
1․1 Overview of the Fluke 179 Model
The Fluke 179 is a high-performance, battery-powered True RMS multimeter designed for precise measurements in industrial and electrical systems․ Part of the 170 Series, it features a 6000-count, 3 3/4-digit display and a bar graph for real-time signal analysis․ It measures voltage, current, resistance, capacitance, temperature, and frequency, offering versatility for various applications․ Known for its durability and reliability, it’s an essential tool for professionals needing accurate diagnostics․
1․2 Key Features and Specifications
The Fluke 179 features True RMS voltage and current measurements, 6000-count resolution, and manual or autorange modes․ It includes a CAT III 1000V and CAT IV 600V safety rating, ensuring safe operation in harsh environments․ The multimeter measures up to 10A AC/DC, 1000V AC/DC, and 50MΩ resistance․ Additional functions include capacitance, temperature, and frequency measurement, with a low-pass filter for noise reduction in motor drives․
Installation and Setup
Unbox and inventory all components, including test leads and battery․ Install the 9V battery and attach the included temperature probe․ Follow manual instructions for setup․
2․1 Unboxing and Initial Inspection
Upon unboxing, inspect the Fluke 179 multimeter for any damage․ Verify all items, including the multimeter, test leads, 9V battery, temperature probe, and user manual․ Ensure the battery is installed correctly and the LCD display is functional․ Check for any signs of wear or damage to the test leads and probes․ Proper inspection ensures optimal performance․
2․2 Battery Installation and Accessories
Install the 9V battery by opening the compartment on the rear․ Ensure the battery is correctly aligned and securely closed․ The multimeter comes with test leads, alligator clips, and a temperature probe․ Verify all accessories are undamaged and properly connected․ These components are essential for accurate measurements and safe operation․
Understanding the User Interface
The Fluke 179 features a 6000-count, 3 3/4-digit display with a bar graph for precise measurements․ The intuitive interface includes a rotary switch and function buttons for easy mode selection․
3․1 Front Panel Controls and Displays
The Fluke 179’s front panel includes a 3 3/4-digit LCD display, a bar graph for real-time signal analysis, and a rotary switch for function and range selection․ The interface also features buttons for mode selection, including manual and autorange options, ensuring quick access to various measurement functions․
3․2 Navigating the Menu System
The Fluke 179’s menu system is accessed via a dedicated button, offering options like zero adjustment, low-pass filter activation, and display contrast settings․ Users can navigate through menus using the rotary switch, with clear on-screen prompts guiding selections․ Pressing and holding the menu button exits to the main measurement mode, ensuring intuitive operation․
Operating Modes
The Fluke 179 operates in Manual Range and Autorange modes, providing flexibility for precise measurements or automatic range selection based on input signal characteristics․
4․1 Manual Range Mode
To enter Manual Range Mode, press the RANGE button until “Manual Range” appears on the display․ This mode allows you to manually select the measurement range for precise control․ Use the RANGE button to cycle through available ranges․ The low pass filter can be enabled in this mode by pressing the yellow button, helping to reduce high-frequency noise for more accurate readings․
4․2 Autorange Mode
Autorange Mode automatically selects the optimal measurement range for the detected input signal, ensuring accurate and efficient readings․ This mode is ideal for quick measurements, as it eliminates the need for manual range adjustments․ The multimeter seamlessly switches between ranges, adapting to varying signal levels and providing reliable results without user intervention․
Basic Measurements
The Fluke 179 measures voltage, current, resistance, and continuity with precision; It features a clear display and intuitive controls for straightforward electrical and electronic system testing․
5․1 Voltage and Current Measurements
The Fluke 179 measures voltage and current with high accuracy, supporting up to 1000V AC/DC and 10A AC/DC․ It uses True RMS for precise readings and offers manual or autorange options․ The multimeter is designed for safety, meeting CAT III 1000V and CAT IV 600V standards, making it ideal for industrial and field applications with reliable performance․
5․2 Resistance and Continuity Testing
The Fluke 179 measures resistance up to 50MΩ with high accuracy and includes a continuity test․ The beeper sounds when a low resistance (less than 30Ω) is detected, aiding in quick circuit troubleshooting․ This feature is essential for identifying short circuits, open circuits, and verifying connections in electrical systems, ensuring efficient and reliable diagnostics․
Advanced Features
The Fluke 179 offers advanced features like frequency measurement, capacitance testing, and temperature measurement with high accuracy․ These capabilities enhance its versatility in complex troubleshooting scenarios․
6․1 Frequency Measurement
The Fluke 179 accurately measures frequency up to 1 kHz for AC voltage and current․ In manual range mode, it displays precise frequency readings, while the bar graph ensures accurate measurements․ This feature is essential for diagnosing electrical systems with varying frequencies, ensuring reliable performance in industrial and field applications․
6․2 Capacitance and Temperature Measurement
The Fluke 179 includes a built-in capacitance measurement function, ideal for testing capacitors in electrical circuits․ It also supports temperature measurement with the included 80BK temperature probe, enabling precise readings in various industrial applications․ These features enhance the multimeter’s versatility for comprehensive system diagnostics and maintenance․
Troubleshooting Common Issues
Troubleshooting common issues with the Fluke 179 involves identifying error messages and applying solutions․ The manual provides clear instructions for resolving frequent problems and restoring functionality․
7․1 Common Error Messages and Solutions
The Fluke 179 may display error messages like “OL” for overload or “0” for open circuits․ These indicate measurement issues․ Solutions include checking leads, ensuring proper connections, or resetting the multimeter to factory settings․ Refer to the manual for specific error codes and detailed troubleshooting steps to resolve common operational problems effectively․
7․2 Resetting to Factory Settings
To reset the Fluke 179 to factory settings, press and hold the “Range” and “Hold” buttons while powering on․ Release when “RESET” appears․ This restores default settings, ensuring accurate measurements and optimal performance, as outlined in the manual․ Always consult the manual for precise instructions to avoid errors during the reset process․
Maintenance and Calibration
Regular maintenance ensures optimal performance․ Replace fuses and batteries as needed․ Calibration involves adjusting settings to meet specifications, ensuring accurate measurements․ Follow manual guidelines for procedures;
8․1 Replacing Fuses and Batteries
Turn off the multimeter and ensure it is safe to handle․ Open the battery compartment, located at the rear, and replace the 9V battery․ For fuses, locate the fuse holder, open it, and pull out the old fuse․ Insert a new fuse of the correct rating․ Always use Fluke-approved replacements to maintain accuracy and safety․ Refer to the manual for specific instructions․
8․2 Calibration Procedures
Calibration ensures accuracy and reliability․ Use a Fluke-approved calibration checker to verify performance․ Adjustments should only be made by authorized personnel․ Refer to the service manual for detailed steps․ Calibration is typically required annually or after significant use․ Always use Fluke-recommended calibration equipment to maintain precision and warranty compliance․ Follow all safety guidelines during the process․
Accessories and Upgrades
Enhance functionality with genuine Fluke accessories, including heavy-duty test leads, alligator clips, and temperature probes․ Optional software enables data logging and analysis, while connectivity upgrades improve efficiency and precision․
9․1 Recommended Test Leads and Probes
For optimal performance, use genuine Fluke test leads with 4mm probes, designed for durability and accuracy․ The multimeter comes with heavy-duty test leads, alligator clips, and a temperature probe․ These accessories ensure reliable measurements and are built to withstand rigorous use in industrial environments․ They are safety-rated and compatible with the Fluke 179’s advanced features, including frequency and capacitance measurements․
9․2 Optional Software and Connectivity
The Fluke 179 supports optional software for enhanced functionality, such as data logging and analysis․ Connectivity options like USB allow users to transfer measurements to a PC for further review․ Fluke also offers dedicated applications for remote monitoring and data management, ensuring seamless integration with industrial systems and improving workflow efficiency․ These tools are designed to maximize the multimeter’s capabilities in professional settings․
Safety Precautions
The Fluke 179 meets CAT III 1000V and CAT IV 600V safety ratings, ensuring safe operation․ Proper handling and storage are essential to maintain accuracy and longevity․
10․1 CAT III 1000V and CAT IV 600V Ratings
The Fluke 179 is rated CAT III 1000V and CAT IV 600V, ensuring safety in high-voltage environments․ These ratings protect against arc faults and transient voltages, making it suitable for industrial and commercial applications․ Compliance with these standards guarantees reliable operation and user protection during measurements․
10․2 Proper Handling and Storage
Always handle the Fluke 179 with care to avoid physical stress or damage․ Store it in a dry, cool place, away from direct sunlight and moisture․ Use the provided protective case to prevent scratches․ Avoid extreme temperatures and ensure the multimeter is clean․ Regularly inspect and clean test leads and probes to maintain accuracy and reliability during measurements․
Warranty and Support
Fluke offers a lifetime warranty for the 179 multimeter, ensuring long-term reliability․ Contact Fluke support via phone or website for assistance with troubleshooting, repairs, or general inquiries․
11․1 Fluke’s Lifetime Warranty
Fluke guarantees the 179 digital multimeter with a lifetime warranty, covering defects in materials and workmanship․ This comprehensive warranty ensures reliability and performance, providing users with peace of mind for years․ The warranty underscores Fluke’s commitment to quality and customer satisfaction, making the 179 a trusted choice for professionals and industries worldwide․
11․2 Contacting Fluke Support
For assistance, contact Fluke support at 1-888-99-FLUKE (1-888-993-5853) in the USA․ Visit their official website for additional resources, troubleshooting, and repair services․ Fluke’s dedicated team is available to address inquiries, ensuring optimal performance and resolving issues promptly․ This support ensures users maximize their multimeter’s capabilities and maintain reliability in their work․
The Fluke 179 multimeter is a reliable, versatile tool for electrical troubleshooting, offering advanced features and durability․ Its comprehensive manual ensures optimal use, supported by Fluke’s commitment to quality․
12․1 Summary of Key Features
The Fluke 179 True RMS multimeter stands out with its CAT III 1000V and CAT IV 600V safety ratings, True RMS voltage and current measurements, and 6000-count resolution․ It features manual and autorange modes, capacitance, temperature, and frequency measurement capabilities․ The device also includes a bar graph display and is supported by Fluke’s lifetime warranty, ensuring reliability and performance․
12․2 Final Tips for Optimal Use
- Always use high-quality test leads to ensure accurate measurements․
- Enable the low pass filter to reduce noise in motor drive applications․
- Regularly update the firmware for the latest features and improvements․
- Store the multimeter in a protective case to prevent damage․
- Refer to the manual for proper calibration procedures to maintain accuracy․
- Use the bar graph function to quickly identify trends or transient signals․
Additional Resources
Access the Fluke 179 manual, online tutorials, and guides for in-depth instructions․ Visit the official Fluke website or authorized distributors like Instrumart for comprehensive support resources․
- Download the full manual from Fluke’s official website․
- Explore online tutorials for advanced troubleshooting techniques․
13․1 Downloading the Full Manual
The Fluke 179 manual is available for free download from Fluke’s official website․ Visit http://us․fluke․com/usen/support/manuals to access the PDF version․ The manual provides detailed operating instructions, specifications, and troubleshooting guides for optimal use of the multimeter․ Ensure you download the correct supplement for the Fluke 179 model to get accurate information․
- Go to the Fluke website․
- Search for the Fluke 179 manual․
- Download the PDF file for offline access․
13․2 Online Tutorials and Guides
Fluke offers comprehensive online resources, including tutorials and guides, to help users master the Fluke 179 multimeter․ Visit Fluke’s official website or platforms like Amazon for detailed PDF manuals, video tutorials, and troubleshooting tips․ These resources provide step-by-step instructions for advanced features like frequency measurement and capacitance testing, ensuring optimal use of the device․
- Access tutorials on Fluke’s website․
- Explore guides on Amazon and other platforms․
- Utilize video tutorials for hands-on learning․
